Prism King 300w Beam Moving Head
Mechanical Specifications:
-Housing: ABS plastic fire-retardant
-Power Connection: PowerCon Type in & out
-Signal Connection: 3 Pin XLR connectors
-Pan Movement: 540º(16 BIT , 3 Phase Stepper Motor)
-Tilt Movement: 270º(16 BIT , 3 Phase Stepper Motor)
-Frost : 1 Frost Filter
-Focus: Linear Focus
-Optical lens : 6-layer high-definition color coating lens
-Color Wheel: 14 Colors+open , with rotating rainbow effect, Bi-direction
-Gobo Wheel: 14 gobos (4xglass + 10xmetal)+ open
-Prism 1 : 8 facet prism
-Prism 2 : 24 honeycomb prisms
-Prism 3 : 48 honeycomb facet prism
-Prism 4 : 6 facet linear prism
-Prisms can be overlapped rotated independently in both directions
-Lens Angle : 0-4°
-Dimming: 0-100% linear dimming
-Cooling : Temperature controlled fan
Electrical Specifications:
-Light Source: 300w lamp
-LED ring : 31×0.5w RGB 3IN1 LED
-Color temperature: 8500K
-Lumen Output : 7950LM
-Power supply: AC 100-240V, 50/60 Hz
-Power Consumption:450w
Control Systems:
-Display : LCD display , Display panel can be 180°flipped
-Operating modes: auto, sound, master-slave, DMX512
-DMX channels: 16/18
Size & Weight:
-Product size : 210x230x510mm
-Net weight: 12.5 kg
-Package size : 51.5x37x40.5 cm
Gross Weight: 14 kg
Prism King 300w Beam is the next generation beam moving head powered by the brilliant 300w MSD Discharge Lamp (1,500 hr.),It features the biggest optical lens to achieve Powerful wide range and sharp beam , Includes: 4 Prism FX, Rainbow wheel, Frost Filter, Motorized Focus, 14 dichroic colors + white, 9 static GOBOs + open and 4 colorful glass gobos.
